High-strength steel plate
Standing inventory of 2,000 tons, contact us via message or email for details.
High-strength steel plate

High Strength Steel Plate is a material used to make several products from plates to sheets. The properties inherent by these plates depend upon the elements added to them. High Strength Steel Plate is one such type of plate that has improved strength, formability, and weldability.

High-strength steel plate advantage

Generally, the tensile strength of high strength steel plate is about 400-450MPa. Hot forming steel is formed by heating. After a series of treatments, the tensile strength can be increased to 1300-1600 MPa, which is 3-4 times that of ordinary steel.High strength steel plate (high strength plate) refers to the brand Q460 steel, high strength, especially in the normalizing or normalizing and tempering state has higher comprehensive mechanical properties.

High-strength steel plate application

 Mainly used in large ships, Bridges, power plant equipment, medium and high pressure boilers, high pressure vessels, rolling stock, lifting machinery, mining machinery and other large welding structural parts.


High-strength steel plate chemical composition

Grade C Si Mn P S Nb V Al Ti Cr Ni Mo N
EN10025-4 S275M 0.15 0.55 1.6 0.035 0.03 0.06 0.1 0.015 0.06 0.35 0.35 0.13 0.017
EN10025-4 S275ML 0.15 0.55 1.6 0.03 0.025 0.06 0.1 0.015 0.06 0.35 0.35 0.13 0.017
EN10025-4 S355M 0.16 0.55 1.6 0.035 0.03 0.06 0.12 0.015 0.06 0.35 0.55 0.13 0.017
EN10025-4 S355ML 0.16 0.55 1.7 0.03 0.025 0.06 0.12 0.015 0.06 0.35 0.55 0.13 0.017
EN10025-4 S420ML 0.18 0.55 1.8 0.03 0.025 0.06 0.14 0.015 0.06 0.35 0.85 0.23 0.027
EN10025-4 S460M 0.18 0.55 1.8 0.035 0.03 0.06 0.14 0.015 0.06 0.35 0.85 0.23 0.027
EN10025-4 S460ML 0.18 0.65 1.8 0.03 0.025 0.06 0.14 0.015 0.06 0.35 0.85 0.23 0.027

High-strength steel plate mechanical property

Grade Yield Strength (MPa) Ultimate Tensile Strength (MPa) Elongation at Break (%)
EN10025-4 S275M 275 370-530 24
EN10025-4 S275ML 355 470-630 22
EN10025-4 S355M 275 370-530 24
EN10025-4 S355ML 355 470-630 22
EN10025-4 S420ML 420 520-680 19
EN10025-4 S460M 460 540-720 17
EN10025-4 S460ML 460 540-720 17

High-strength steel plate Product Specification

Thickness:

0.2-500mm,etc

Width :

1000-4000mm,etc

Length:

2000mm, 2438mm, 3000mm, 3500,6000mm,12000mm,or rolled,etc etc

Standard:

ASTM,AISI,JIS,GB, DIN,EN

Surface:

Black painted,PE coated,Galvanized,color coated,

anti rust varnished,anti rust oiled,checkered,etc

Technique:

Cold Rolled, Hot Rolled

Certification:

ISO, SGS,BV

price terms:

FOB,CRF,CIF,EXW all acceptable

Delivery Detail:

inventory About 5-7; custom-made 25-30

Loading port:

any port in China

Packing:

standard export packing (inside:water proof paper,outside:steel covered with strips and pallets)

Payment Terms:

T/T, L/C at sight,West Union,D/P,D/A,Paypal

Container size:

20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)

40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)

40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)

Hot Products

checkered carbon steel plate suppliers china high carbon steel plate
cheap mild carbon steel plate china mild carbon steel plate factory
cheap low temperature carbon steel plate china q235b carbon steel plate
cheap hot rolled carbon steel plate cold drawn carbon steel plate
cheap carbon steel plate steel cold rolled carbon steel plate sheet
china carbon steel plate common carbon steel plate
china carbon steel plate factory china a53 carbon steel plate
china carbon steel plate suppliers china carbon structural steel plate

Application

Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.

Oil and GasKuwait is a country of petroleum resources with abundant, oil factory also is very broad, respectively, the oil plant are mainly used for refining oil and oil processing.
MarineSubmarine pipelines carry such things as domestic water, waste water, electrical lines, gas lines, communication lines, and outfall or intake systems.
ConstructionBridge materials with high strength, low cost for selecting the main basis, give priority to with development of the traditional steel and concrete.
EnergyEngineering is mainly aiming at the water pollution and solid waste pollution. using the steel pipe to filtrate in order to improve the quality of water.

Export area

We are a well known worldwide supply and export High-strength steel plate in following countries:,Italy, Philippines, France,Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
