hydraulic steel pipe
Strong Strength, High-Quality Products
hydraulic steel pipe

The hydraulic tube is cylinder-like shaped tubing device that when attach to hydraulic systems, allow for the passage of fluids within and among components. The tube standard specifies dimensions for cold drawn finishing and seamless precision steel tubes.

Advantages of hydraulic pressure

Compared with mechanical transmission and electrical transmission, hydraulic transmission has the following advantages:

1. Various components of hydraulic transmission can be arranged conveniently and flexibly according to needs.
2, light weight, small size, small movement inertia, fast reaction speed.
3, easy control, can achieve a wide range of stepless speed regulation (speed range up to 2000:1).
4, can automatically realize overload protection.
5, the general use of mineral oil as the working medium, the relative movement surface can be self-lubricating, long service life;
6, easy to achieve linear motion /
7, it is easy to realize the automation of the machine, when the electro-hydraulic joint control, not only can realize a higher degree of automatic control process, but also can realize remote control.

Hydraulic Steel Pipe Description

Cold-rolled precision seamless steel pipe is made of seamless steel pipe finished pipe or seamless pipe waste, after pickling, phosphating, saponification treatment, and then rolled by cold rolling machine into hydraulic steel pipe.The hydraulic tube is cylinder-like shaped tubing device that when attach to hydraulic systems, allow for the passage of fluids within and among components. The tube standard specifies dimensions for cold drawn finishing and seamless precision steel tubes. Cold drawn process provides the tube with close dimensional tolerances, increase material strength and enhanced machinability. Therefore, hydraulic tubes are suitable in high performance piping system application.

What is the material of hydraulic tube?

There are two type of material grade, ST52.4 and ST37.4. ST52.4 is high tensile strength tube means it has higher permissible working pressures by reduced tube wall thickness, and leading to reduced system overall weight.

Hydraulic Steel Pipe Chemical Composition

Grade S N Al Cr Cu Mo Ni Nb
DIN17102 EStE285 0.02  0.2 0.2 0.3 0.2 0.08 0.3 0.03
DIN17102 StE315 0.03  0.2 0.2 0.3 0.2 0.08 0.3 0.03
DIN17102 StE355 0.03  0.2 0.2 0.3 0.2 0.1 0.3 0.05
DIN17102 StE380 0.03  0.2 0.2 0.3 0.2 0.1 1 0.05
DIN17102 StE420 0.03  0.2 0.2 0.3 0.2 0.1 1 0.05
DIN17102 StE460 0.03  0.2 0.2 0.3 0.2 0.1 1 0.05
DIN17102 TStE315 0.03  0.2 0.2 0.3 0.2 0.08 0.3 0.03
DIN17102 WStE315 0.03  0.2 0.2 0.3 0.2 0.08 0.3 0.03
DIN17102 WStE500 0.03  0.2 0.2 0.3 0.2 0.1 1 0.05

Hydraulic Steel Pipe Mechanical Property

Grade Yield Strength (MPa) Ultimate Tensile Strength (MPa) Elongation at Break (%)
DIN17102 StE315 285 440-560 24
DIN17102 EStE285 315 440-560 23
DIN17102 TStE315 355 490-630 22
DIN17102 WStE315 380 500-650 20
DIN17102 StE355 420 530-680 19
DIN17102 StE380 460 560-730 17
DIN17102 StE420 315 440-560 23
DIN17102 StE460 315 440-560 23
DIN17102 WStE500 500 610-780 18

Hydraulic Steel Pipe Specification


hydraulic steel pipe


Boiler Pipe, Hydraulic Pipe, Gas Pipe, OIL PIPE, Structure Pipe, Other

Section Shape



0.20-50mm or as request





Surface Treatment

Hot Rolled



Processing Service

Welding, Punching, Cutting, Bending, Decoiling

Delivery Time



1 Ton

Payment Term

30%TT Advance + 70% Balance


Seaworthy Standard Package

Price Term



Provide Sample Service


Mill Edge Slit Edge


Thirdy Inspection Party


High Temperature Resistance

Factory Display

Factory Display

Tianjin tisco is a one-stop steel pipe supplier for global manufacturers.

Hot sale product

wholesale hydraulic steel pipe factories hydraulic steel pipe factory
wholesale hydraulic steel pipe hydraulic steel pipe factories
steel pipe for hydraulics hydraulic stainless steel pipe for sale
stainless steel hydraulic pipe suppliers china hydraulic steel pipe supplier
stainless steel hydraulic pipe manufacturers china hydraulic steel pipe manufacturers
stainless steel hydraulic pipe manufacturer china hydraulic steel pipe factory


Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.

Oil and GasKuwait is a country of petroleum resources with abundant, oil factory also is very broad, respectively, the oil plant are mainly used for refining oil and oil processing.
MarineSubmarine pipelines carry such things as domestic water, waste water, electrical lines, gas lines, communication lines, and outfall or intake systems.
ConstructionBridge materials with high strength, low cost for selecting the main basis, give priority to with development of the traditional steel and concrete.
EnergyEngineering is mainly aiming at the water pollution and solid waste pollution. using the steel pipe to filtrate in order to improve the quality of water.

Exporting country

We are a well known worldwide supply and export hydraulic steel pipe in following countries:,Italy, Philippines, France,Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.


Welcome to Tianjin Tisco. We are a comprehensive enterprise integrating steel trading and processing. We provide one-stop service for global customers. Complete specifications, exported all over the world, factory direct sales, integrity management. Meet all your needs for steel!
