Hydraulic seamless tubes are typically made of several alloys and solid round steel bars of metals such as stainless steel, carbon steel, tungsten, etc. These metal pieces are converted into hollow tubes by heating and rolling over to the required forms.Seamless tubes are considered to be strong enough to resist high pressure from numerous industrial forces. This is not possible in a welded tube, because, a seam or joint acts as a weak section for the tube.

hydraulic seamless pipe

J524 seamless hydraulic oil pipe

Hydraulic Seamless Pipe Advantage

hydraulic seamless pipe advantage
1、Smooth interior and exterior surfaces
2、No seams or welds
3、Thick scale-free surface
4、High-pressure resistance
5、Superior performance
6、High corrosion resistance
7、Elevated durability
8、Robustness
0、High tensile strength
10、High-reliability factor

Hydraulic Seamless Pipe Description

Hydraulic seamless tubes are typically made of several alloys and solid round steel bars of metals such as stainless steel, carbon steel, tungsten, etc. These metal pieces are converted into hollow tubes by heating and rolling over to the required forms.Seamless tubes are considered to be strong enough to resist high pressure from numerous industrial forces. This is not possible in a welded tube, because, a seam or joint acts as a weak section for the tube. A hydraulic seamless tube is specifically designed to resist dynamic loads and high static offering an enduring, staunch solution.

Hydraulic Seamless Pipe Application

Hydraulic seamless tubes are widely used in petrochemical industries, refineries, power industries, chemical industries, aerospace industries, automotive industries, etc. Heat exchanger tubes, hydraulic tubes, boiler tubes, mechanical tubes, finned tubes, etc. required in these industries are hydraulic seamless tubes.

Hydraulic Seamless Pipe Chemical Composition

Grade	C	Mn	Si	P	S	Nb	V	Al	Ti	Cr	Mo	N	Ni
EN10025-3 S275N	0.2	0.45-1.60	0.45	0.035	0.03	0.06	0.07	0.015	0.06	0.35	0.13	0.017	-
EN10025-3 S275NL	0.2	0.45-1.60	0.45	0.03	0.035	0.06	0.07	0.015	0.06	0.35	0.13	0.017	-
EN10025-3 S355N	0.2	0.85-1.75	0.55	0.035	0.03	0.06	0.14	0.015	0.06	0.35	0.13	0.017	0.55
EN10025-3 S355NL	0.2	0.95-1.75	0.55	0.03	0.025	0.06	0.14	0.015	0.06	0.35	0.13	0.017	0.85
EN10025-3 S420N	0.2	0.95-1.80	0.65	0.035	0.03	0.06	0.22	0.015	0.06	0.35	0.13	0.027	0.85
EN10025-3 S420NL	0.22	0.95-1.80	0.65	0.03	0.025	0.06	0.22	0.015	0.06	0.35	0.13	0.027	0.85
EN10025-3 S460N	0.22	0.95-1.80	0.55	0.035	0.03	0.06	0.22	0.015	0.06	0.35	0.13	0.027	0.85
EN10025-3 S460NL	0.22	0.95-1.80	0.65	0.03	0.025	0.06	0.22	0.015	0.06	0.35	0.13	0.027	0.85

Hydraulic Seamless Pipe Mechanical Property

Grade	Yield Strength (MPa)	Ultimate Tensile Strength (MPa)	Elongation at Break (%)
EN10025-3 S275N	275	370-510	23
EN10025-3 S275NL	275	370-510	23
EN10025-3 S355N	355	470-630	21
EN10025-3 S355NL	355	470-630	21
EN10025-3 S420N	420	520-680	18
EN10025-3 S420NL	420	520-680	18
EN10025-3 S460N	460	540-720	17
EN10025-3 S460NL	460	540-720	17

Hydraulic Seamless Pipe Specification

Type		hydraulic seamless pipe
Materials		API 5L /A53 /A106 GRADE B and other material which client inquired
^Size	Outer Diameter	Seamless:17-914mm 3/8"-36"
	Wall Thickness	SCH10 SCH20 SCH30 STD SCH40 SCH60 XS SCH80 SCH100 SCH120 SCH140 SCH160 XXS
	Length	Single random length/Double random length 5m-14m,5.8m,6m,10m-12m,12m or as customer's actual request
Ends		Plain end/Beveled,protected by plastic caps on both ends, cut quare,grooved,threaded and coupling,etc.
Surface Treatment		Bare,Painting black,varnished,galvanized,anti-corrosion 3PE PP/EP/FBE coating
Technical Methods		Hot-rolled/Cold-drawn/Hot-expanded
Testing Methods		Pressure test,Flaw detection,Eddy current testing, Hydro static testing or Ultrasonic examination and also with chemical and physical property inspection
Packaging		Small pipes in bundles with strong steel strips,large pieces in loose; Covered with plastic woven bags; Wooden cases; Suitable for lifting operation; Loaded in 20ft 40ft or 45ft container or in bulk; Also according to customer's requests
Origin		China
Application		Conveying oil gas and water
Third Party Inspection		SGS BV MTC
Trade Terms		FOB CIF CFR
Payment Terms		FOB 30%T/T, 70% before shipment CIF 30% pre-payment and the balance to be paid before making shipment or Irrevocable 100% L/C at sight
MOQ		10 tons
Supply Capacity		5000 T/M
Delivery Time		Usually within 10-45 days after receipt of advance payment

Hot sale product

wholesale hydraulic steel pipe factories	hydraulic steel pipe factory
wholesale hydraulic steel pipe	hydraulic steel pipe factories
steel pipe for hydraulics	hydraulic stainless steel pipe for sale
stainless steel hydraulic pipe suppliers	china hydraulic steel pipe supplier
stainless steel hydraulic pipe manufacturers	china hydraulic steel pipe manufacturers
stainless steel hydraulic pipe manufacturer	china hydraulic steel pipe factory

Application

Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.

Oil and GasKuwait is a country of petroleum resources with abundant, oil factory also is very broad, respectively, the oil plant are mainly used for refining oil and oil processing.

MarineSubmarine pipelines carry such things as domestic water, waste water, electrical lines, gas lines, communication lines, and outfall or intake systems.

ConstructionBridge materials with high strength, low cost for selecting the main basis, give priority to with development of the traditional steel and concrete.

EnergyEngineering is mainly aiming at the water pollution and solid waste pollution. using the steel pipe to filtrate in order to improve the quality of water.

Exporting country

We are a well known worldwide supply and export hydraulic seamless pipe in following countries：,Italy, Philippines, France，Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
