Precision steel pipe is a kind of high precision steel pipe material after cold drawing or hot rolling. Due to the advantages of no oxide layer on the inner and outer walls of precision steel pipe, no leakage under high pressure, high precision, high finish, cold bending no deformation, flaring, flattening without cracks, etc., it is mainly used for the production of pneumatic or hydraulic components, such as cylinder or cylinder, can be seamless pipe, but also welded pipe.

Precision Steel Pipe

precision seamless steel pipe

high precision steel pipe

Precision Steel Pipe features

1. Smaller outside diameter.

2. High precision can be done in small batches.

3. The cold drawing product has high precision and good surface quality.

4. The cross area of the steel pipe is more complex.5. The steel pipe has better performance and the metal is dense.

5. The cold drawing product has high precision and good surface quality.

6. The cross area of the steel pipe is more complex.

7. The steel pipe has better performance and the metal is dense.

Precision steel pipe application

Precision steel pipe is widely used in automobiles, motorcycles, electric vehicles, petrochemical, electric power, ships, aerospace, bearings, pneumatic components, medium and low pressure boiler seamless steel pipe and other fields, can also be applied to steel bar sleeve, bearings, hydraulic, mechanical processing and other fields!

Precision steel pipe chemical composition

Speci -cation	Grade	Chemical Composition [%]
		C		Mn		P	S	Si		Cr		Mo		Cu	Ni	V
		C		Mn		P	S	Si		Cr		Mo		Cu	Ni	V
		Min	Max.	Min	Max.	Max.	Max.	Min.	Max	Min.	Max	Min.	Max	Max	Max	Max
ASTM A192		0.06	0.18	0.27	0.63	0.035	0.035	-	0.25	-	-	-	-	-	-	-
ASTM A210	A-1	-	0.27	-	0.93	0.035	0.035	0.1	-	-	-	-	-	-	-	-
ASTM A210	C	-	0.35	0.29	1.06	0.035	0.035	0.1	-	-	-	-	-	-	-	-
ASTM A213	T-11	0.05	0.15	0.3	0.6	0.025	0.025	0.5	1	1	1.5	0.44	0.65	-	-	-
	T-12	0.05	0.15	0.3	0.61	0.025	0.025	-	0.5	0.8	1.25	0.44	0.65	-	-	-
	T-22	0.05	0.15	0.3	0.6	0.025	0.025	-	0.5	1.9	2.6	0.87	1.13	-	-	-
ASTM A335	P-11	0.05	0.15	0.3	0.6	0.025	0.025	0.5	1	1	1.5	0.44	0.65	-	-	-
	P-12	0.05	0.15	0.3	0.61	0.025	0.025	-	0.5	0.8	1.25	0.44	0.65	-	-	-
	P-22	0.05	0.15	0.3	0.6	0.025	0.025	-	0.5	1.9	2.6	0.87	1.13	-	-	-
BS 3059 Pt I	320	-	0.16	0.3	0.7	0.04	0.04	0.1	0.35	-	-	-	-	-	-	-
BS 3059 Pt II	622-490	0.08	0.15	0.4	0.7	0.03	0.03	-	0.5	2	2.5	0.9	1.2	-	-	-
DIN 1629	St- 37.0	-	0.17	-	-	0.04	0.04	-	-	-	-	-	-	-	-	-
DIN 1629	St - 52	-	0.22	-	-	0.04	0.035	-	-	-	-	-	-	-	-	-
DIN 17175	St - 35.8	-	0.17	0.4	0.8	0.04	0.04	0.1	0.35	-	-	-	-	-	-	-
DIN 17175	St - 45.8	-	0.21	0.4	1.2	0.04	0.04	0.1	0.35	-	-	-	-	-	-	-

Precision Steel Pipe mechanical property

Speci -cation	Grade	Mechanical Properties
		Yield Strength		Tensile Strength			% Elongation (G.L. 50 mm WT 8 mm) e (min.)
		Min.		Min.
		PSI	MPa	PSI	MPa
ASTM A179	-	26,000	180	47,000	325	35
ASTM A192		26,000	180	47,000	325	35
ASTM A210	A-1	37,000	255	60,000	415	30
	C	40,000	275	70,000	485	30
ASTM A213	T-11	30,000	205	60,000	415	30
	T-12	32,000	220	60,000	415	30
	T-22	30,000	205	60,000	415	30
ASTM A335	P-11	30,000	205	60,000	415	30
	P-12	32,000	220	60,000	415	30
	P-22	30,000	205	60,000	415	30
BS 3059 Pt I	320	28,000	195	46,000	320	69,500
BS 3059 Pt II	622-490	40,000	275	71,000	490	93,000
DIN 1629	St- 37.0	WT 16mm = 235 WT>16mm = 225		350		-
	St - 52	WT 16mm = 355 WT>16mm = 345		-		Long 21 Trans 19
DIN 17175	St - 35.8	WT 16mm = 235 WT>16mm = 225		360		480
	St - 45.8	WT 16mm = 255 WT>16mm = 245		410		530

Precision Steel Pipe Specification

Precision steel pipe
Standard	ASTM, AISI,JIS, DIN2391，DIN2445, EN10305,GB/T3639,GB/T8713, GOST
Grade	A36,A53(A,B) ,A106(B,C) , A179-C,SAE1010 ,1020, 1035/S35C ,1045/S45C/CK45 , E235/S235JR, E355/S355JR, ST35、ST37、ST45、ST52,20CR4 ,41CR4, 4130,15CRMO,20CRMO, 34CRMO4/4135/SCM435, 42CRMO4/4140/SCM440, ST35.8 ,ST37.2 , ST42 ST52.4 ,100CR6,STKM11A,STKM12B,STKM13A,
Size	OD	5mm - 610mm, or as the customer’s request
	Thickness	0.2mm - 60mm or as the customer’s request
	Length	10mm-12000mm or as the customer’s request
Section Shape	Round/Rectangular/Square/Other Special shapes
Surface	Bright and smooth, no scratches, no pitting
Application	Structure Pipe, Precision machine parts, Parts for Car,Auto and Motorcycle .Sleeve Pipe.PTO shaft,For Agricultural Parts and so on
Technique	Cold Drawn/ Cold rolled/ Grinding / Polishing
Certification	CE,ISO
Surface Treatment	oiled/black painting
Tolerance	±0.02MM,
Type	Seamless Steel Pipe/Welded steel pipe
Processing Service	Bending, Welding, Decoiling, Punching, Cutting
MOQ	No MOQ for stock Size, 50 KG for our production.
Delivery Condition	NBK(+N)GBK(+A)BK(+C)BKW(+LC)BKS(+SR)
Packing	Export standard package: bundled wooden box, suit for all kinds of transport,or be required
Inspection	Party Inspection
Payment terms	T/T, L/C, Western Union, Alibaba Trade Assurance, etc
Price term	Ex-work, FOB, CIF, CFR, etc
Delivery time	Within 3 days for our stock size, 10-30 days for our production

Hot sale product

china cold rolled high precision seamless steel pipe	precision stainless steel pipe
china cold rolled high precision seamless steel pipe factories	precision stainless steel pipe factories
china cold rolled high precision seamless steel pipe factory	precision stainless steel pipe factory
china cold rolled high precision seamless steel pipe manufacturer	precision stainless steel pipe manufacturer
china cold rolled high precision seamless steel pipe manufacturers	precision stainless steel pipe quotes
china cold rolled high precision seamless steel pipe supplier	precision stainless steel pipe supplier

Application

Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.

Oil and GasKuwait is a country of petroleum resources with abundant, oil factory also is very broad, respectively, the oil plant are mainly used for refining oil and oil processing.

MarineSubmarine pipelines carry such things as domestic water, waste water, electrical lines, gas lines, communication lines, and outfall or intake systems.

ConstructionBridge materials with high strength, low cost for selecting the main basis, give priority to with development of the traditional steel and concrete.

EnergyEngineering is mainly aiming at the water pollution and solid waste pollution. using the steel pipe to filtrate in order to improve the quality of water.

Exporting country

We are a well known worldwide supply and export Precision Steel Pipe in following countries：,Italy, Philippines, France，Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
