Shipbuilding steel plate

Shipbuilding steel plate refers to hot-rolled steel for the manufacture of ship structures produced in accordance with the requirements of the construction society. Often used as a special steel ordering, scheduling, sales, a ship including ship plates, steel and so on.

Shipbuilding steel plate

AH36 marine steel

DH32 marine steel

AH32 marine steel

Grade E marine steel

Grade D marine steel

Grade B marine steel

Grade A marine steel

EH36 marine steel

Ship building steel plate classification

Ship building steel plate refers to the hot-rolled steel sheet produced in accordance with the Classification Society building code for the manufacture of ship structures.According to its small yield point, the strength of Marine steel plates is divided into general strength structural steel and high strength structural steel. Structural steel for ship hull is divided into two kinds: general strength steel and high strength steel. General strength steel is divided into four grades according to its mass: A, B, C and D. High strength steel is divided into two strength grades (32, 36) and three quality grades (A, D, E), the main specifications are AH32, DH32, EH32, AH36, DH36, EH36.

Shipbuilding steel plate chemical composition

Grade	C	Si	Mn	P	Su	V	Al	Cr	Cu	Mo	Nb	Ni	Ti
ABS AH36	0.18	0.1-0.5	0.90-1.6	0.035	0.035	0.05-0.10	0.015	0.2	0.35	0.08	0.02-0.05	0.4	0.02

Shipbuilding steel plate mechanical property

Grade	Yield Strength (MPa)	Ultimate Tensile Strength (MPa)	Elongation at Break (%)
ABS AH36	355	490-620	21

Product Specification

Product Name	Ship building steel plate naval plate boat plate
Length	4m-12m or as required
Width	0.6m-3m or as required
Thickness	3mm-300mm or as required
Standard	AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Technique	Hot rolled
Surface Treatment	Clean, blasting and painting according to customer requirement
Thickness tolerance	±0.1mm
Material	A32,D32,E32,F32,D36,E36,F36,A40,D40 AH36,DH32,DH36,EH32,EH36,FH36 CCS-A,CCS-B,CCSA,CCSB,CCS,CCSD,CCSE GL-B,GL-D,GL-E
Application	To prevent the hull from being corroded by chemical corrosion, electrochemical corrosion and sea life and microorganisms.It is used in make ship body ,decks etc.
MOQ	1tons.We also can accept sample order.
Shipment time	Within 15-20 workdays after receiving deposit or L/C
Export packing	Waterproof paper, and steel strip packed. Standard Export Seaworthy Package. Suit for all kinds of transport,or as required.
Capacity	250,000 tons/year
