Grade B marine steel
Grade B marine steel Description:
Grade B marine steel is a kind of hot rolled general tensile strength steel. The ABS B grade steel plates have yield strength of 34,100 psi (235 MPa), and ultimate tensile strength of 58,000 - 75,500 psi (400-520 MPa). ABS steels come 4 grades in ordinary-strength steel for shipbuilding and grade B is one of them.
Grade B marine steel Application:
ABS B Shipbuilding steel plates can be used for ship repairing, the offshore oil drilling platform, the platform pipe joints and other components. ABS B grades of steel plate are almost exclusively used in the Shipbuilding Industry for the construction of structural parts of ships, barges and marine equipment.Grade B marine steel Specification:
Thickness: 4mm to 260mm,Width: 1200mm to 4000mm
Length: 3000mm to 18000mm.
Grade B marine steelChemical Composition
| Element | ABS Grade B Max % | Element | ABS Grade B max % |
C | 0.21 | Ni | - |
Mn | 0.80 | Mo | - |
Si | 0.35 | Al | - |
S | 0.035 | Nb | - |
P | 0.035 | V | - |
Cu | - | Ti | - |
Cr | - | N |
Grade B marine steel Mechanical Properties
Grade | Thickness | Yield Strength | Tensile Strength | Elongation | Impact Energy |
(mm) | MPa (min) | MPa | % (min) | (KV J) (min) | |
0 degree | |||||
ABS Grade B | 4-260 | 235 | 400-520 | 22 | 27J |
marine steel specification
The structure of the hull plate Steel offshore platforms | A B C D E(Z15 Z25 Z35) | CCS,DNV,GL |
AH32-FH32(Z15 Z25 Z35) | LR,BV,ABS | |
AH36-FH36(Z15 Z25 Z35) | KR,NK,RINA | |
AH40-EH40(Z15,Z25,Z35) |
| |
APISPEC2H Gr.42.Gr.50 | GB5313,API |
production workshop
production workshop
production workshop
production workshop
