Hastelloy C-276 advantage
The alloy has excellent corrosion resistance to most corrosive media in oxidation and reduction states. Excellent resistance to point corrosion, crack corrosion and stress corrosion cracking. Alloys are suitable for a variety of chemical process industries containing oxidizing and reducing media. The high content of molybdenum and chromium makes the alloy resistant to chloride ions, and tungsten further improves its corrosion resistance. Hastelloy C-276 is one of the only materials capable of resisting the corrosion of humid chlorine, hypochlorite and chlorine dioxide solutions. The alloy is remarkably resistant to high concentrations of salt chloride solutions (e.g. Ferric chloride and copper chloride).
Hastelloy C-276 description
Hastelloy C276 Pipe is a titanium stabilized chromium nickel molybdenum alloy. This combination has a number of advantages and provides a high range of mechanical properties. Steel India Company is a Hastelloy C276 Pipe Manufacturer of pipes in this range of specification. There are Hastelloy C276 Seamless Pipe products which are highly corrosion resistant to most corrosive media. The specialty of these pipes is the pitting and crevice corrosion resistant. It is wrought metallic pipe specification with high strength as well. We produce the Hastelloy C276 Welded Pipe which has all the mechanical properties and the addition of easy welding ability.
Hastelloy C-276 chemical composition
| Hastelloy C276 | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr |
| Balance | 0.010 max | 15.00 – 17.00 | 1.00 max | 0.08 max | 4.00 – 7.00 | 0.04 max | 0.03 max | 2.5 max | 14.50 – 16.50 |
Hastelloy C-276 mechanical property
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.89 g/cm3 | 1370 °C (2550 °F) | Psi – 1,15,000 , MPa –790 | Psi – 52,000 , MPa – 355 | 40 % |
Hastelloy C-276 specification
Product Name | hastelloy c276 |
Material | Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy |
Shape | Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet |
Grade | Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L |
Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc | |
Alloy : Alloy 20/28/31 | |
Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g | |
Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C, Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602, Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665 | |
Haynes: Haynes 230/556/188 | |
Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20 | |
Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851, Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 / UNS N06600 / DIN W. Nr. 2.4816 | |
Incoloy: Incoloy 800/800H/800HT/825/925/926; | |
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044 | |
Monel: Monel 400/K500/R405 | |
Nitronic: Nitronic 40/50/60; | |
Nimonic: Nimonic 75/80A/90/A263 ; | |
Specification | Wire: 0.01-10mm |
Product Characteristics | 1.According to the preparation process can be divided into deformation superalloys, |
Standard | GB,AISI,ASTM,DIN,EN,SUS,UNS etc |
Inspection | ISO,SGS,BV and so on. |
Application | High temperature components such as turbine blades, guide vanes, turbine disks, high pressure compressor disks,machine manufacturing |
Packaging | 1. cases packed in wooden cases |
Delivery | 7-25days orAccording to the product |
Payment | L/C,D/A,D/P,T/T,Western Union,MoneyGram,According to customer requirements payments |
production workshop
production workshop
production workshop
production workshop
hot sale product
| hastelloy c276 | hastelloy d205 |
| c276 hastelloy | wholesale hastelloy x wire |
| wholesale hastelloy x strip factory | wholesale hastelloy x tube |
| hastelloy x | wholesale hastelloy x strip factory |
| hastelloy metal | wholesale hastelloy x strip |
| hastelloy c | wholesale hastelloy x sheet |
| hastelloy c-276 | wholesale hastelloy x plate |
| wholesale hastelloy c22 | hastelloy c22 |
Application
Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.
Hastelloy outlet
We are a well known worldwide supply and export Hastelloy in following countries：,Italy, Philippines, France，Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
