Electroplating grid plate Product Description

Electroplating grid plate Description

Electroplating grid plate is the alias of steel grid plate, is the use of flat steel in accordance with a certain distance and cross bar cross arrangement, and welded into a kind of steel products with square lattice in the middle, mainly used to do ditch cover plate, steel structure platform plate, steel ladder step plate, etc. As a new material and a new product, the twisted square steel is widely used in cross bar. Its superior performance and good performance-price ratio show its application prospect.

Electroplating grid plate Classification

1、Ordinary hot-dip galvanized grating plate
After the bearing flat steel groove cutting, the horizontal bar flat link compression lock forming.The maximum processing height of the ordinary grille plate is 100mm.The length of the grille plate is usually less than 2000mmm.
2、integral type hot-dip galvanized grid plate
The bearing plane and the transverse bar plane have the same height and the groove depth is 1/2 of the bearing plane.
The height of the grille plate shall not be greater than 100mm.
The length of the grille plate is usually less than 2000mm.
3、 Sun shading type hot-dip galvanized grating plate
Bearing flat steel open 30° or 45° oblique slot, slot rod flat steel slotted pressure lock forming.
According to different needs can be handed over other spacing, specifications of the grid plate, can use ordinary carbon, stainless steel, aluminum and other materials.
The height of the grille plate is less than 100mm.
4、 Heavy-duty hot-dip galvanized grille plate.It is formed by the interlocking of the high plenum and the cross bar plenum under the pressure of 1200 tons.Suitable for high span load bearing occasions.

Electroplating grid plate Product Specification
