aluminum diamond plate Product Description
aluminum diamond plate advantage
Embossed aluminum diamond plate sheets are light-weight, and easy to install making them ideal for use on walls and other low-impact applications. With a thickness of .025 inches are made from 3104 aluminum to provide superior strength and durability. aluminum diamond plate sheets are easy to clean and provide strong long lasting protection along with superior corrosion resistance. Contractors, manufacturers, and installers commonly use this material on walls inside and out.
aluminum diamond plate application
With great corrosion resistance, this material is commonly used for rock guards and siding by trailer, RV and camper manufactures. Common applications for this embossed diamond plate include: Garage walls, fitness centers, mechanical rooms, cafeterias, food trucks, trailer manufactures, storage facilities, car wash, grow facilities,
Aluminum diamond deck plates are used in parking lots, stairs, loading docks, boats and other Marine applications and much, much, more…，
aluminum diamond plate Classification
1、High Polish Diamond Plate: Features an impressive mirror like sheen and surface finish.
2、Gloss Black Diamond Plate: Features a dark and glossy, smooth version for a more modern and clean look
3、Metallic Grey Diamond Plate: Features a less shiny, more industrial look and finish
4、Race Red Diamond Plate: Features a red finish
aluminum diamond plate Product Specification
Item | aluminum diamond plate |
Type | Double Zero Foil for Lamination |
Alloy Type | 1000-8000 series |
Thickness & Tolerance | 0.1-50mm ( Tolerance=±6% ) |
Width & Tolerance | 280mm-1500mm ( Tolerance:1mm ) |
Inner Core Materials | Steel, Aluminum core |
Steel,Aluminum core | Tensile Strength(U.T.S): 35 MPA - 100 MPA Elongation≥0.5% |
Standard | GB3198 ( China National Standard ) |
Packaging | Seaworthy Export Standard Wooden Box |
Application | Decorative, anti-skid, pedal |
aluminum diamond plate Chemical composition
| Element | % Present |
| Cu | 0-0.05 |
| Mg | 0-0.05% |
| Si | 0-0.25% |
| Fe | 0-0.4% |
| Mn | 0-0.05% |
| Zn | 0-0.07% |
| Ti | 0-0.05% |
| Al | Balance |
Mechanical Properties aluminum diamond plate
| BS EN 485-2:2008 | |
| Sheet | |
| 0.2mm to 6.00mm | |
| Property | Value |
| Proof Stress | 85 Min MPa |
| Tensile Strength | 105 – 145 MPa |
| Hardness Brinell | 34 HB |
| Elongation A | 12 Min % |
production workshop
production workshop
production workshop
production workshop
Other Products
| 48 x 48 aluminum sheet | aluminum sheet 5052 h32 |
| 24 x 36 aluminum sheet | aluminum sheet 6061 |
| 3/16 4x8 aluminum sheet | aluminum sheet alloys |
| 3/8 aluminum sheet | aluminum sheet buy |
| 3004 aluminum sheet | aluminum sheet corrugated |
| 3mm aluminum sheet | aluminum sheet diamond plate |
Application
Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.
Export area
We are a well known worldwide supply and export Tread plate in following countries：,Italy, Philippines, France，Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
