NM 550 Wear Resistant Steel plate Wear Resisting Steel description
NM500 is a high strength wear-resistant steel plate, which has high abrasion resistance. Brinell hardness of 500 (HBW) is mainly used to provide protection for wear-resistant occasions or parts, so that the service life of the equipment is longer, and the maintenance and shutdown brought by maintenance are reduced, and the corresponding investment of funds is reduced.
NM 550 Wear Resistant Steel plate Wear Resisting Steel application
NM500 wear-resistant steel plate is widely used in engineering machinery, environmental protection machinery, metallurgical machinery, grinding tools, bearings and other product parts.
NM 550 Wear Resistant Steel plate Wear Resisting Steel chemical composition
composition | C | Si | Mn | P | S | Cr | Mo | Ni | Bt | CEV |
nm500 | ≤0.38 | ≤0.70 | ≤1.70 | ≤0.020 | ≤0.010 | ≤1.20 | ≤0.65 | ≤1.00 | 0.005-0.006 | 0.65 |
nm500 | 130 | 2 | 7 | 7 | 6 | 1 | 7 | 5 | 1 | goods in stock |
NM 550 Wear Resistant Steel plate Wear Resisting Steel mechanical property
Grade | thickness | strength of extension | extend rate | —20℃Impact work (longitudinal)AKV/J | Brinell Hardness HBW | cold bend |
NM500 | 6～60 | — | — | ≥24 | 480～525 | Sample width B=30MM bending Angle 180° bending center diameter dw4n |
NM 550 Wear Resistant Steel plate Wear Resisting Steel specification
Product Name | Hot Rolled Wear Resistant Abrasion Resistant Mild Steel Plate Sheet NM400 NM450 NM500 |
Length | 4m-12m or as required |
Width | 0.6m-3m or as required |
Thickness | 3mm-300mm or as required |
Standared | AISI, ASTM ,DIN, JIS, GB, JIS, SUS, EN, etc. |
Technique | Hot rolled |
Surface Treatment | Clean, blasting and painting according to customer requirement |
Thickness tolerance | ±0.1mm |
Material | NM450L,NM450A,NM600,NM400,NM400L,NM400A,NM500A,NM500,NM360L,NM360,NM550,NM450, NR360,NR400,MITTA 400F,MITTA 450F,MITTA 500F |
Application | It is widely used in mining machinery,environmental protection machinery, cement machinery, engineering machinery etc due to it is high wear resistance. |
MOQ | 25tons.We also can accept sample order. |
Shipment time | Within 15-20 workdays after receiving deposit. |
Export packing | Waterproof paper, and steel strip packed. |
Capacity | 250,000 tons/year |
production workshop
production workshop
production workshop
production workshop
hot sale product
| Wear resistant corten steel plate | china Wear Resisting Steel plate |
| Wear steel plates | china Wear steel plate manufacturers |
| Wear steel tread plate | chinese Wear steel check plate |
| Wear Resisting Steel plate price | chinese Wear steel checker plate |
| nm500 Wear Resisting Steel plate | corten a/b Wear steel plate |
| nm450 Wear Resisting Steel plate | corten Wear steel plate |
| Wear Resisting Steel plate | nm400 Wear Resisting Steel plate |
| Wear Resisting Steel plates supplier | Wear Resisting Steel plates manufacturer |
Application
Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.
Export area
We are a well known worldwide supply and export nm500 wear-resistant steel plate in following countries：,Italy, Philippines, France，Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
