Duplex stainless steel description
Duplex stainless steels are a family of stainless steels. These are called duplex grades because their metallurgical structure consists of two phases, austenite (face-centered cubic lattice) and ferrite (body centered cubic lattice) in roughly equal proportions.
They are designed to provide better corrosion resistance, particularly chloride stress corrosion and chloride pitting corrosion, and higher strength than standard austenitic stainless steels such as Type 304 or 316. They are therefore used extensively in the offshore oil and gas industry for pipework systems, manifolds, risers, etc. and in the petrochemical industry in the form of pipelines and pressure vessels.
Applications of Duplex Stainless Steel
Duplex stainless steels are usually selected for their high mechanical properties and good to very high corrosion resistance (particularly to stress corrosion cracking).
Architecture：Stockholm's waterfront building ，Louvre Abu Dhabi，La Sagrada Familia
Infrastructure：Helix Bridge，Singapore ，Cala Galdana bridge ，Hong Kong–Zhuhai–Macau bridge and undersea tunnel ，sea walls, piers, etc.
Oil and Gas：a wide range of equipment: flowlines, manifolds, risers, pumps, valves, etc.
Pulp and Paper：digesters, pressure vessels, liquor tanks, etc.
Chemical engineering：pressure vessels, heat exchangers, condensers, distillation columns, agitators, marine chemical tankers, etc.
Duplex stainless steels Mechanical Property
| Mechanical Property | Value |
|---|---|
| Proof Stress | 450 Min MPa |
| Tensile Strength | 620 Min MPa |
| Elongation A50 mm | 25 Min % |
| Hardness Brinell | 290 Max HB |
Composition of Duplex stainless steel
| Chemical Element | Carbon (C) | Chromium (Cr) | Manganese (Mn) | Silicon (Si) | Phosphorous (P) | Sulphur (S) | Nickel (Ni) | Nitrogen (N) | Molybdenum (Mo) | Iron (Fe) |
| % Present | 0.0 - 0.03 | 21.00 - 23.00 | 2.00 max | 1.00 max | 0.0 - 0.03 | 0.0 - 0.02 | 4.50 - 6.50 | 0.08 - 0.20 | 2.50 - 3.50 | Balance |
Specifications of Duplex Stainless Steel
Material | Stainless steel sheet | |||
Surface | 2B/BA/NO.4/NO.5/HL mirror/8K | |||
Grade | DIN GB JIS BA Al SI ASTM EN etc | |||
Certificate | MTC SGS BV | |||
Technique | hot rolled or cold rolled | |||
Thickness | 0.3-3mm or as required | |||
Width | 10-1500mm or as required | |||
Length | 2000-3000mm or as required | |||
Stainless steel coil has a good oxidation resistance and intensity of medium temperature. So it is widely used in decoration, sugical instruments, household appliances, cookware. lableware automobile and other industry construction. | ||||
MOQ | 5 Metric ton | |||
Delivery time | Within 7-15 working days after receiving the balance payment | |||
Capacity | 250,000 tons/year | |||
production workshop
production workshop
production workshop
production workshop
hot sale products
| 1 16 stainless steel plate | 1 2 stainless steel threaded plate |
| 10mm stainless steel plate | 1/8 inch stainless steel plate home depot |
| 12mm stainless steel plate | 18-8 stainless steel threaded plate |
| 5 32 stainless steel plate | 3/8 316 stainless steel threaded plate |
| 316 stainless steel threaded plate | pro-shot stainless steel cleaning plates |
| 5mm stainless steel plate | plate stainless steel |
| bending stainless steel plate | 1 32 stainless steel plate |
| .125 stainless steel plate | 1 4 inch diameter stainless steel plate |
Application
Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.
stainless steel plate outlet
We are a well known worldwide supply and export stainless steel plate in following countries：,Italy, Philippines, France，Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
