polished stainless steel angle
Strong Strength, High-Quality Products

Product Description

What is polished stainless steel angle and what is it used for?

Polished stainless-steel angle is produced from 304 grade steel and is used to make frames and as an edging trim.

We offer this trim in bright polish or dull satin polish finish which has fine grain line running along the length of the profile.

This grade of stainless steel is very versatile as it has good corrosion resistance, excellent weldability, and excellent formability.

Polishing method

(1) "cloth wheel stick wax" polishing.it is to polish the abrasive combined with the cloth wheel.

(2) sandpaper polishing.Place the stainless steel workpiece on the workbench or other platform, replace the coarse and fine sandpaper, and polish by hand.

(3) Angle grinder polishing
The operator holds an Angle grinder and installs 120# or/and 220# small grinding tools (Angle grinder accessories) on the Angle grinder to polish the workpiece. Before polishing, it is sometimes necessary to install a common resin Angle grinder for rough grinding. After polishing, PVA abrades are sometimes re-polished with a felt wheel for a brighter finish.

(4) Polishing by pneumatic grinder
The pneumatic grinder in the production shop is equipped with grinding wheel and polishing wheel for polishing stainless steel plates with an area of less than 1 square meter.

(5) grinding machine polishing
Polishing on the surface grinder, install the grinding wheel, select the appropriate workpiece speed, polishing stainless steel workpiece highlight surface quality.

(6) floating grinding head polishing
The floating grinding head is polished on a self-made floating grinding head. Cloth wheels made of expensive materials are polished with an area of about 1 square meter of stainless steel plate. You can get the fog mirror effect.

Product Specification

Name

polished stainless steel angle

Standard

AISI ASTM JIS SUS DIN GB



Material

Stainless Steel / Carbon Steel

201/202/304/316/Q235/Q345/A36/Q235/SS400/Duplex stainless steel,etc

A32,AH32,A36,AH36,DH36,D32 DH32 10# 20# 45# Q195 Q215 Q235 Q345 Q235b Q355b SS490 SM400 SM490 SPHC SPHD SPHE SPHF SEA1002 SEA1006
SEA1008 SEA1010 S25C S35C S45C 65Mn SPHT1 SPHT2 SPH3 SPH4 QstE or customiz

Technology

Hot-rolled, Cold rolled

Length

3000mm~12000mm or as customer' s requirement

Widthness

3mm~2000mm or customized

Shape

angle bar

Surface

natural color,black,mill,polished,brush,galvanized etc

Application

Mechanical & Manufacture, Steel strcuture, Shipbuilding, Bridging, Automobile Chassis, etc.

Chemical composition of polished stainless steel angle

Grade C Mn Si P S Cr Ni Fe N
Stainless Steel 304 0.0 - 0.07 0.0 - 2.0 0.0 - 1.00 0.0 - 0.05 0.0 - 0.03 17.50 - 19.50 8.00 - 10.50 Balance 0.0-0.11

Mechanical property of polished stainless steel angle

Grade Proof Stress (MPa) Tensile Strength (MPa) Hardness Brinell
Stainless Steel 304 276 310 123 HB
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop

Hot sale product

stainless steel angle iron prices stainless steel 304 angle bar
polished stainless steel angle trim stainless steel angle 1/16
stainless steel corner angle stainless steel angle 2mm
stainless steel l angle stainless steel angle 304
stainless steel equal angle stainless steel angle bar supplier
stainless steel unequal angle sizes stainless steel angle manufacturer

Application

Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.

Oil and GasKuwait is a country of petroleum resources with abundant, oil factory also is very broad, respectively, the oil plant are mainly used for refining oil and oil processing.
MarineSubmarine pipelines carry such things as domestic water, waste water, electrical lines, gas lines, communication lines, and outfall or intake systems.
ConstructionBridge materials with high strength, low cost for selecting the main basis, give priority to with development of the traditional steel and concrete.
EnergyEngineering is mainly aiming at the water pollution and solid waste pollution. using the steel pipe to filtrate in order to improve the quality of water.

Our export country

We are a well known worldwide supply and export stainless steel angle in following countries:,Italy, Philippines, France,Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
