304Lstainless steel pipe features
304L stainless steel tube 18CR-8Ni-low carbon as a low C 304 steel, in the general state, its corrosion resistance is similar to 304 steel, but after welding or stress relief, its grain boundary corrosion resistance is excellent; In the case of no heat treatment, also can maintain good corrosion resistance, the use of temperature -196℃~800℃. Used in chemical, coal and petroleum industries with high corrosion resistance to grain boundaries, outdoor machines, heat-resistant parts of building materials and parts with difficulty in heat treatment.
304Lstainless steel pipe application
Household products (Class 1 and 2 tableware, cabinets, indoor pipelines, water heaters, boilers, bathtubs), automobile accessories (windshield wipers, molding products), medical equipment, building materials, chemicals, food industry, agriculture, Marine parts;
304Lstainless steel pipe chemical composition
Chemical Composition (%) of 304L Stainless Steel
| Chromium | Nickel | Carbon | Manganese | Phosphorus | Sulfer | Silicon | Nitrogen |
| 18.0 min.-20.0 max. | 8.0 min.-12.0 max. | 0.030 | 2.00 | 0.045 | 0.030 | 0.75 | 0.10 |
304Lstainless steel pipe mechanical property
Chemical Composition (%) of 304L Stainless Steel
| 0.2% Offset Yield Strength, ksi | Ultimate Tensile Strength, ksi | Elongation in 2 inches, % | Hardness, Rockwell B |
| 25 min. | 70 min. | 40 min. | 92 max. |
304Lstainless steel pipe specification
Grade | 201/202/301/303/304/304L/316/316L/321/309S/310S/401/409/410/410S/420/420J1/420J2/430/439/443/444/2205/2507/2020/253MA/904L |
Surface Finish | 2B, BA, NO.1, NO.4, 8K, HL, Embossing, Satin, Mirror, brush, ect |
Standard | JIS/SUS/GB/DIN/ASTM/AISI/EN |
Technique | Cold Rolled; Hot Rolled |
Thickness | 0.3-4mm cold rolled; 3-16mm hot rolled; 16-100mm hot rolled; Customized according to customer requirements |
Width | 1000mm, 1219mm, 1240mm, 1500mm, 1800mm, 2000mm,or as required |
Length | 2000mm, 2438mm, 2500mm, 3000mm, 6000mm or as required |
Color | Interior/Exterior decoration; Architectur; Evevator; Kitchen; Ceiling; Cabinet; Advertising nameplate; Roof structure; |
Lead Time | 7-15 working days after the receipt of 30% deposit |
Payment Terms | TT/LC |
Price Terms | FOB, EXW, CIF, CFR |
