Stainless Steel Square Bar
Strong Strength, High-Quality Products

Stainless Steel Square Bar Description

There are mainly cold - rolled stainless steel square and hot - rolled stainless steel square. 304 stainless steel square steel is a long stainless steel bar with a square cross section. 304 stainless steel square steel has the advantages of light weight, high temperature resistance, corrosion resistance, etc.304 is the most used grade of stainless steel with excellent weldability and good corrosion resistance. 316 has excellent corrosion resistance and weldability but is harder to machine.Stainless steel square is highly durable and corrosion resistant – perfect for projects that may be exposed to the elements, including extreme temperatures.

Stainless Steel Square Bar applications

Supports,Piers,Concrete footings,Railings,Ornamental work,Beams


The difference between 304 and 316 stainless steel square steel

The Grade 304 Square Bar is made up of the 304 grade of stainless steel which has 18% chromium and 8% nickel in the composition and possesses 515MPa minimum tensile strength, 205MPa minimum yield strength and up to 870 degrees Celsius operating temperatures. The Stainless Steel 316 Box Bar is made up of similar material with added molybdenum to the composition which makes it more corrosion resistant than the 304 bar. The material has similar mechanical properties except for the improved corrosion resistance against salt water and chloride iron rich solutions

Stainless Steel Square Bar chemical composition

Typical chemical requirements
304 304L 316/316L 321
Carbon, Max % 0.07 0.03 0.03 0.08
Manganese, Max % 2 2 2 2
Phosphorus, Max % 0.045 0.045 0.045 0.045
Sulphur, Max % 0.03 0.03 0.03 0.03
Silicon Max 0.75 0.75 0.75 0.75
Chromium range 17.5-19.5 17.5-19.5 16-18 17-19
Nickel range 8.0-10.5 8-12 10-14 9-12
Nitrogen Max 0.1 0.1 0.1 0.1

Stainless Steel Square Bar mechanical property

Mechanical Properties
304 304L 316/316L 321
Tensile Min 75 ksi 70 ksi 75 ksi 75 ksi
Yield Min 30 ksi 25 ksi 25 ksi 30 ksi
Elongation Min 40% 40% 40% 40%
Hardness Max 95 HRB 95 HRB 95 HRB 95 HRB

Stainless Steel Square Bar Specification

Product Name

Stainless Steel Square Bar




Diameter: 3mm-800mm

Length: 3m,4m,5.8m,6m,11.8m or other length

Type:Round bar/Square bar/Hexagonal bar

Surface Treatment

Natural black, Bright ,Polishing ,Peeled, or as your requirement


Stainless Steel Bar is mianly used in

1:Electric power,petroleum,boiler, high temperature resistant,
low temperature resistant,corrosion resistant
2:Tableware, cabinet, cutting tool, boiler, auto part
3:Medical instruments, building materials, food industry
4:Sea,chemical industry and Machine Manufacture


Samples can be provided by samples charges.

Delivery Time

Prompt or negotiated.

Export to

Most countries worldwide.

production workshop
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop
production workshop

Hot sale product

Hexagonal square steel tube 1 mm square steel tube
1/8 square steel tube 316 square steel tube
square steel tube 3/16 5 16 square steel tube
1 2 square steel tube 5 8 square steel tube
3/8 square steel tube 1 4 inch square steel tube
1/8 square steel tube 1/2 in square steel tube


Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.

Oil and GasKuwait is a country of petroleum resources with abundant, oil factory also is very broad, respectively, the oil plant are mainly used for refining oil and oil processing.
MarineSubmarine pipelines carry such things as domestic water, waste water, electrical lines, gas lines, communication lines, and outfall or intake systems.
ConstructionBridge materials with high strength, low cost for selecting the main basis, give priority to with development of the traditional steel and concrete.
EnergyEngineering is mainly aiming at the water pollution and solid waste pollution. using the steel pipe to filtrate in order to improve the quality of water.

our export country

We are a well known worldwide supply and export Alloy Steel Plate in following countries:,Italy, Philippines, France,Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
