Stainless Steel Square Bar Description
There are mainly cold - rolled stainless steel square and hot - rolled stainless steel square. 304 stainless steel square steel is a long stainless steel bar with a square cross section. 304 stainless steel square steel has the advantages of light weight, high temperature resistance, corrosion resistance, etc.304 is the most used grade of stainless steel with excellent weldability and good corrosion resistance. 316 has excellent corrosion resistance and weldability but is harder to machine.Stainless steel square is highly durable and corrosion resistant – perfect for projects that may be exposed to the elements, including extreme temperatures.
Stainless Steel Square Bar applications
Supports，Piers，Concrete footings，Railings，Ornamental work，Beams
.
The difference between 304 and 316 stainless steel square steel
The Grade 304 Square Bar is made up of the 304 grade of stainless steel which has 18% chromium and 8% nickel in the composition and possesses 515MPa minimum tensile strength, 205MPa minimum yield strength and up to 870 degrees Celsius operating temperatures. The Stainless Steel 316 Box Bar is made up of similar material with added molybdenum to the composition which makes it more corrosion resistant than the 304 bar. The material has similar mechanical properties except for the improved corrosion resistance against salt water and chloride iron rich solutions
Stainless Steel Square Bar chemical composition
| Typical chemical requirements | ||||
| 304 | 304L | 316/316L | 321 | |
| Carbon, Max % | 0.07 | 0.03 | 0.03 | 0.08 |
| Manganese, Max % | 2 | 2 | 2 | 2 |
| Phosphorus, Max % | 0.045 | 0.045 | 0.045 | 0.045 |
| Sulphur, Max % | 0.03 | 0.03 | 0.03 | 0.03 |
| Silicon Max | 0.75 | 0.75 | 0.75 | 0.75 |
| Chromium range | 17.5-19.5 | 17.5-19.5 | 16-18 | 17-19 |
| Nickel range | 8.0-10.5 | 8-12 | 10-14 | 9-12 |
| Nitrogen Max | 0.1 | 0.1 | 0.1 | 0.1 |
Stainless Steel Square Bar mechanical property
| Mechanical Properties | ||||
| 304 | 304L | 316/316L | 321 | |
| Tensile Min | 75 ksi | 70 ksi | 75 ksi | 75 ksi |
| Yield Min | 30 ksi | 25 ksi | 25 ksi | 30 ksi |
| Elongation Min | 40% | 40% | 40% | 40% |
| Hardness Max | 95 HRB | 95 HRB | 95 HRB | 95 HRB |
Stainless Steel Square Bar Specification
Product Name | Stainless Steel Square Bar | |||
Material | ASTM | |||
Specification | Diameter: 3mm-800mm Length: 3m,4m,5.8m,6m,11.8m or other length Type:Round bar/Square bar/Hexagonal bar | |||
Surface Treatment | Natural black, Bright ,Polishing ,Peeled, or as your requirement | |||
Application | Stainless Steel Bar is mianly used in | |||
Samples | Samples can be provided by samples charges. | |||
Delivery Time | Prompt or negotiated. | |||
Export to | Most countries worldwide. | |||
production workshop
production workshop
production workshop
production workshop
Hot sale product
| Hexagonal square steel tube | 1 mm square steel tube |
| 1/8 square steel tube | 316 square steel tube |
| square steel tube 3/16 | 5 16 square steel tube |
| 1 2 square steel tube | 5 8 square steel tube |
| 3/8 square steel tube | 1 4 inch square steel tube |
| 1/8 square steel tube | 1/2 in square steel tube |
Application
Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.
