What is Stainless Steel Hexagonal Bar?
The Stainless Steel Hex Bars have enhanced strength and that is why they are used in a wide range of applications. The additional strength is due to the geometric shape of the hex bars. If the hex bar is made of austenitic stainless steel, then they have greater strength and higher corrosion resisting properties. The Stainless Steel Hex Bars can be customized to different shapes and sizes according to the specific requirements. The characteristics of the hex bars is also dependent on its chemical composition. Most of the stainless steel products have chromium and nickel in its alloy, which also enhances its corrosion resistance and strength properties. Because of this, they are seen in several structural and construction applications.
Stainless Steel Hexagonal Bar advantage
1, stainless steel hexagonal bar dimension accuracy is high, up to ±0.01mm; Size: hexagonal bar size: H2-H90mm;
2, stainless steel hexagonal bar surface quality is good, good brightness;
3, stainless steel hexagonal bar has strong corrosion resistance, high tensile strength and fatigue strength;
4, stainless steel hexagonal bar chemical composition is stable, pure steel, low inclusion content;
The difference between 304 and 316Stainless Steel Hexagonal Bar
1、The ss 304 material consists of 18% chromium, and 8% nickel, whereas the ss 316 material has 16% chromium, 10% nickel, and 2% molybdenum.
2、The addition of the molybdenum helps to enhance the corrosion resistance properties of the 316 Stainless Steel Hex Bar.
3、The 304 material comes with a higher melting point but the 316 grade ss offers higher resistance to chlorides and chemicals.
Stainless Steel Hexagonal Bar chemical composition
| Typical chemical requirements | ||||
| 304 | 304L | 316/316L | 321 | |
| Carbon, Max % | 0.07 | 0.03 | 0.03 | 0.08 |
| Manganese, Max % | 2 | 2 | 2 | 2 |
| Phosphorus, Max % | 0.045 | 0.045 | 0.045 | 0.045 |
| Sulphur, Max % | 0.03 | 0.03 | 0.03 | 0.03 |
| Silicon Max | 0.75 | 0.75 | 0.75 | 0.75 |
| Chromium range | 17.5-19.5 | 17.5-19.5 | 16-18 | 17-19 |
| Nickel range | 8.0-10.5 | 8-12 | 10-14 | 9-12 |
| Nitrogen Max | 0.1 | 0.1 | 0.1 | 0.1 |
Stainless Steel Hexagonal Bar mechanical property
| Mechanical Properties | ||||
| 304 | 304L | 316/316L | 321 | |
| Tensile Min | 75 ksi | 70 ksi | 75 ksi | 75 ksi |
| Yield Min | 30 ksi | 25 ksi | 25 ksi | 30 ksi |
| Elongation Min | 40% | 40% | 40% | 40% |
| Hardness Max | 95 HRB | 95 HRB | 95 HRB | 95 HRB |
Stainless Steel Hexagonal Bar Specification
Name | Stainless Steel Hexagonal Bar /Hex Rod Steel | |||
Type | 201/202/301/304/316/2205/441/442/430 | |||
Standard | JIS/SUS/GB/DIN/ASTM/AISI/EN | |||
Technique | Cold Rolled; Hot Rolled | |||
Material | AISI:201/304/316L/310S/321/2205/430 | |||
Diameter | 3-480mm | |||
Length | 3000mm, 4000mm,5800mm,6000mm,12000mm,or as required. | |||
Surface | NO.1/2B/BA/NO.4/8K/SB/HL/Embosses/Etched/Decorate color stainless steel | |||
Usage | Stainless steel bar is widely used in some fields, such as: chemical industry equipment ,industrial tanks,medical | |||
Processing | Bending/Welding/Decoiling/Punching/Cutting | |||
Packing | Standard Seaworthy Package or according to customer's requirements | |||
Delivery | within 7-10 working days after reveiving the deposit or according to your order quantity | |||
Payment | TT/LC etc | |||
MOQ | 1 Ton | |||
production workshop
production workshop
production workshop
production workshop
Hot sale product
| Stainless Steel Hexagonal Bar | 1 mm stainless steel bar |
| stainless steel 1/8 bar | 316 stainless steel bar |
| stainless steel bar 3/16 | 5 16 stainless steel bar |
| 1 2 stainless steel bar | 5 8 stainless steel bar |
| 3/8 stainless steel bar | 1 4 inch stainless steel bar |
| 1/8 stainless steel bar | 1/2 in stainless steel bar |
Application
Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.
our export country
We are a well known worldwide supply and export Alloy Steel Plate in following countries：,Italy, Philippines, France，Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
