316 stainless flat bar advantage
1、Due to the addition of Mo element, its corrosion resistance, and high temperature strength has been greatly improved, high temperature resistance can reach 1200-1300 degrees, can be used under harsh conditions.
2、316 stainless flat bar corrosion resistance is better than 304 stainless steel, in the pulp and paper production process has good corrosion resistance. 316 stainless steel is also resistant to the erosion of the ocean and erosive industrial atmosphere.
3、316 stainless flat bar has good welding performance. All standard welding methods can be used for welding. When welding, 316Cb, 316L or 309Cb stainless steel filler rod or electrode can be used for welding according to the purpose.
316 stainless flat bar application
The main uses are pulp and paper equipment heat exchanger, dyeing equipment, film washing equipment, pipeline, coastal area building external materials.It is also used in the field of solenoid valve, mainly used in shell, clamp, ball, valve body, valve seat, nut, valve stem, etc.Seawater equipment, chemical, dye, paper, oxalic acid, fertilizer and other production equipment; Photography, food industry, coastal facilities, ropes, CD rods, bolts, nuts.
316 stainless flat bar chemical composition
Chemical Composition (%) of 316 Stainless Steel
| C | Mn | Si | P | S | Cr | Mo | Ni | N |
| 0.08 | 2.00 | 0.75 | 0.045 | 0.03 | 16.0-18.0 | 2.00-3.00 | 10.0-14.0 | 0.10 |
316 stainless flat bar mechanical property
Mechanical Properties of 316 Stainless Steel
| 0.2% Offset Yield Strength, ksi | Ultimate Tensile Strength, ksi | Elongation in 2 inches, % | Hardness, Rockwell B |
| 25 min | 70 min | 40 min | 95 max |
316 stainless flat bar specification
Product name | 316 stainless flat bar |
200 series: 201,202,202Cu,204Cu, stainless steel flat bar stainless steel flat bar | |
300series: stainless steel flat bar stainless steel flat bar stainless steel flat bar 301,303/Cu,304/L/H,304Cu,305,309/S,310/S,316/L/H/Ti,321/H,347/H,330, | |
400 series: 409/L,410,416/F,420/F,430,431,440C,441,444,446, | |
600 series: 13-8ph,15-5ph,17-4ph,17-7ph(630,631),660A/B/C/D, | |
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760,2304,LDX2101.LDX2404,LDX4404,904L stainless steel flat bar | |
Others: 153Ma,254SMo,253Ma,654SMo,F15,Invar36,1J22,N4,N6 etc | |
Surface finish | Black,bright,rough turned,grinding,centreless Ground etc stainless steel flat bar |
Diameter | 0.5-500mm 304 Stainless Steel 304 Stainless Steel 304 Stainless Steel |
Tolerance | H8,H9 or as required 304 Stainless Steel 304 Stainless Steel 304 Stainless Steel |
Length | <12000mm or according to customer's special request 304 Stainless Steel |
Technique | Hot Rolled,Cold Rolled,Cold Drawn,Forged |
production workshop
production workshop
production workshop
production workshop
Browse more
| 1.5 mm stainless steel rod | 1 2 inch stainless steel threaded rod |
| 1/16 stainless steel rod | 1 8 diameter stainless steel rod |
| 1/2 inch stainless steel rod | 1 8 inch stainless steel rod |
| 1/2 stainless steel threaded rod | 1 diameter stainless steel rod |
| 1/8 inch stainless steel rod | 1 inch diameter stainless steel rod |
| 10 32 stainless steel threaded rod | 1 inch stainless steel rod |
| 10mm 316 stainless steel rod | 1 inch stainless steel threaded rod |
| 10mm stainless steel rod price | 1 mm diameter stainless steel rod |
Application
Our steel products are mainly used in chemical industry, petrochemical industry, offshore, seawater pipeline, desalination plant, nuclear engineering, paper and pulp industry.
Our export country
We are a well known worldwide supply and export stainless steel flat bar in following countries：,Italy, Philippines, France，Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
